Drawing, "Pedal Shaft Retainer Brkt," Ford GPW, February 12, 1942
01
Artifact Overview
The Ford Motor Company created over a million parts drawings from 1903 to 1957. Many of these drawings specify engineering requirements for the components of Ford-made vehicles--including automobiles, trucks, tractors, military vehicles and Tri-motor airplanes. Others document assembly components, stages of casting and forging, or experimental designs. Beginning in the 1940s, Ford transferred the drawings to microfilm.
Artifact Details
Artifact
Technical drawing
Subject Date
12 February 1942
Collection Title
Location
By Request in the Benson Ford Research Center
Object ID
86.1.1701.GPW.2467.02121942
Credit
From the Collections of The Henry Ford. Gift of Ford Motor Company.
Color
Black-and-white (Colors)
Dimensions
Height: 70 mm
Width: 95 mm
Keywords |
|---|
