Rejector Circuit Board, Type SE-3523, 1918
01
Artifact Overview
In radio's early years, as airwaves grew more crowded, amateur operators and commercial transmitting stations alike were frustrated by static interference. Interference was human generated or atmospheric; common culprits included proximity to AC power lines or overlapping transmissions from multiple stations. The rejector circuit board diminished and eliminated
unwanted, intrusive wireless signals, resulting in clear reception of a desired channel.
Artifact Details
Artifact
Circuit board
Date Made
1918
Creators
Place of Creation
Location
Not on exhibit to the public.
Object ID
37.573.124
Credit
From the Collections of The Henry Ford.
Material
Cast Iron
Copper alloy
Nickel (Metal)
Steel (Alloy)
Wood (Plant material)
Dimensions
Height: 19.5 in
Width: 6 in
Length: 14 in
Inscriptions
front:
Rejector
Type SE-3523 Serial No. W6
W.N.Y. 1918
dial:
0 - 150
Switches:
1 - 9
Load Coil Short Circuit
Rejector IN
condensers (3):
Dubilier Cond. Co.
N.Y.C.
77
