Components of a Spark Plug for a 1937 Ford V-8 Bus (Photograph of an Illustration)
01
Artifact Overview
Spark plugs ignite the air-fuel mixture in an internal combustion engine's cylinders. High voltage jumps across a gap between two electrodes on the plug's bottom and creates a spark. The plug's top is connected to a wire that runs to the distributor, which in turn is connected to the ignition coil and the battery.
Artifact Details
Artifact
Photographic print
Date Made
16 July 1937
Subject Date
1937
Collection Title
Location
By Request in the Benson Ford Research Center
Object ID
P.833.68550.14
Credit
From the Collections of The Henry Ford. Gift of Ford Motor Company.
Material
Paper (Fiber product)
Technique
Gelatin silver process
Color
Black-and-white (Colors)
Dimensions
Height: 11 in
Width: 7.75 in
