Diagrams of Herb Deutsch's Original Moog Synthesizer, February 1982
01
Artifact Overview
These circuit diagrams are graphic representations of the electronics that powered Robert Moog's first prototype synthesizer, built for Herbert Deutsch. Individual "modules" on the synthesizer allowed sounds to be shaped into infinite possibilities; these diagrams address the pitch control, envelope generator, amplifier, band pass filter, noise generator, and trigger extractor.
Artifact Details
Artifact
Diagram
Date Made
February 1982
Location
Not on exhibit to the public.
Object ID
82.68.4
Credit
From the Collections of The Henry Ford.
Material
Paper (Fiber product)
Technique
Printing (Process)
Color
Blue
Dimensions
Height: 11 in
Width: 8.5 in (folded)
Width: 17 in (unfolded)
