Floor Plan, Ford Motor Company Piquette Avenue Plant, First Floor, 1907
01
Artifact Overview
Ford Motor Company quickly outgrew its first factory on Detroit's Mack Avenue and moved into the newly constructed Piquette Avenue Plant in 1904. This floor plan shows how some of the plant's rooms and workspaces were being used a few years later. When Ford grew too big for the three-story Piquette building, it moved into larger quarters in 1910.
Artifact Details
Artifact
Technical drawing
Date Made
28 August 1953
Subject Date
1907
Creators
Location
By Request in the Benson Ford Research Center
Object ID
RC.6.X3358
Credit
From the Collections of The Henry Ford.
Material
Paper (Fiber product)
Technique
Photographic processes
Printing (Process)
Color
Black-and-white (Colors)
Dimensions
Height: 3.25 in (Card)
Width: 7.375 in (Card)
Height: 1.375 in (Film)
Width: 1.875 in (Film)
