Drawing, Frame and Cup Assembly for Ford Rear Attached Mower Model 14-93, February 27, 1959
01
Artifact Overview
The Ford Motor Company created over a million parts drawings from 1903 to 1957. Many of these drawings specify engineering requirements for the components of Ford-made vehicles--including automobiles, trucks, tractors, military vehicles and Tri-motor airplanes. Others document assembly components, stages of casting and forging, or experimental designs. Beginning in the 1940s, Ford transferred the drawings to microfilm.
Artifact Details
Artifact
Technical drawing
Subject Date
27 February 1959
Collection Title
Location
By Request in the Benson Ford Research Center
Object ID
86.1.1701.148148.02271959
Credit
From the Collections of The Henry Ford. Gift of Ford Motor Company.
Color
Black-and-white (Colors)
Dimensions
Width: 70 mm
