Flow Chart for B-24 Production at the Willow Run Bomber Plant, 1944
Add to SetSummary
During World War II, Ford built 8,685 B-24 Liberator bombers at Willow Run. Fuselages were joined to center wing sections and landing gear, after which the airplanes moved along four parallel assembly lines where noses and tails were added. These lines merged into two for the installation of wingtips, engines, and other components. A single final line handled finishing steps and fueling.
