Early Design Sketch of the Edison2 Very Light Car, 2008
01
Artifact Overview
This sketch of the Edison2 was drawn freehand in a coffee shop; it might appear hasty, but its creator is an aerodynamics engineer -- an expert in stealth aircraft technology with decades of wind tunnel experience. While the next steps involved computer-aided design, rough explorations like this were crucial to the development -- and final shape -- of the Edison2.
Artifact Details
Artifact
Sketch
Date Made
August 2008-September 2008
Creators
Collection Title
Location
at Henry Ford Museum in Driving America
Object ID
2011.199.4
Credit
From the Collections of The Henry Ford. Gift of Barnaby Wainfan.
Dimensions
Height: 8.5 in.
Width: 11 in.
