Cutaway Drawing of 1961 Ford Econoline Delivery Van
01
Artifact Overview
Ford took a cue from Volkswagen's popular Type 2 Transporter vans and introduced its own Econoline vans for 1961. This cutaway view shows that, unlike the rear-engine Volkswagen, Ford's Econoline mounted its engine just behind the front axle, with a driveshaft sending power to the rear wheels. The Econoline was built on the compact Ford Falcon platform.
Artifact Details
Artifact
Photographic print
Date Made
1960-1961
Subject Date
1961
Creators
Collection Title
Location
By Request in the Benson Ford Research Center
Object ID
84.1.1660.726
Credit
From the Collections of The Henry Ford. Gift of Ford Motor Company.
Material
Paper (Fiber product)
Technique
Gelatin silver process
Color
Black-and-white (Colors)
Dimensions
Height: 8.625 in
Width: 11 in
