Flywheel Housing Molding at the Ford Rouge Plant Foundry, 1930
01
Artifact Overview
Workers at the Ford Rouge plant's foundry poured a molten mixture of metal, coke, and limestone into molds to create cast-metal engine blocks and parts. Once "shaken out" of their molds, castings were roughly machined before heading elsewhere for finishing and assembly. The Rouge foundry set an industry benchmark in 1932 by successfully casting Ford's intricate, single-piece V-8 engine block.
Artifact Details
Artifact
Photographic print
Date Made
30 September 1930
Subject Date
30 September 1930
Place of Creation
Collection Title
Location
By Request in the Benson Ford Research Center
Object ID
84.1.1660.P.833.55431
Credit
From the Collections of The Henry Ford. Gift of Ford Motor Company.
Material
Paper (Fiber product)
Linen (Material)
Technique
Gelatin silver process
Color
Black-and-white (Colors)
Dimensions
Height: 8 in
Width: 10 in
Inscriptions
On right lower front corner: 55431
Handwritten in pencil on back: Foundry
